Features of Siemens Siprotec 5 7SJ82 Overcurrent & Feeder Protection Relay
Introduction
The Siprotec 5 7SJ82 relay Protection hand-off is a multi-utilitarian engine assurance transfer. It is intended for the security of offbeat engines, everything being equal. The transfers have every one of the necessary capacities to be applied as a reinforcement hand-off to a transformer differential hand-off. The Siemens Siprotec 5 7SJ82 Overcurrent & Feeder Protection Relay elements have adaptable security capacities. Up to 20 extra assurance capacities can be made by the client. Subsequently, insurance of progress for recurrence or opposite power assurance can be acknowledged, for instance. The hand-off gives electrical switch control, further exchanging gadgets, and robotization capacities. The coordinated programmable rationale (CFC) permits the client to add their own capacities, for example for the robotization of switchgear (interlocking). The client is likewise permitted to create client characterized messages.
Highlights-Conformal coating available (NEW)-Pluggable current and voltage terminals-Binary input thresholds settable using DIGSI (3 stages)-Secondary current transformer values (1 A / 5 A) settable using DIGSI-9 programmable function keys-6-line display-Buffer battery exchangeable from the front-USB front port-2 additional communication ports-Integrated switch for low-cost and redundant optical Ethernet rings-Ethernet redundancy protocols RSTP, PRP and HSR for highest availability-Relay-to-relay communication through Ethernet with IEC 61850 GOOSE-Millisecond-accurate time synchronization through Ethernet with SNTP (over Port A or Port B)-Number of binary inputs and binary outputs by connection from up to two SICAM I / O-Units extendable.
Features Of Siemens 7SJ82 Relay
- 4 current transformers
- 0/3 voltage transformers
- 3/7 binary inputs
- Pluggable current and voltage terminals
- Conformal coating available
- 1 life contact
- 0/5 RTD inputs
Functions Of Siemens 7SJ82 Relay
- Overcurrent protection
- Directional overcurrent protection
- Sensitive dir./non-dir. ground-fault detection
- Motor protection
- Undercurrent monitoring
- Starting time supervision
- Thermal Overload Protection
- Breaker failure protection
- Unbalance-load protection
- Lockout
If you are looking forward to the best services & relay products do visit us for quality services as we are the leading product and service providers in the market.
To explore more products of Siprotec 5 click here!
