A brief overview of the Siemens 7SK80 Siprotec Compact Motor Protection Numerical Relay

The Siemens 7SK80 Siprotec Compact Motor Protection Numerical Relay is a sophisticated motor protection device designed to enhance the performance and reliability of power systems. As motors are crucial components of power systems, protecting them from faults and failures is critical to ensuring that the entire system functions efficiently and effectively. The 7SK80 Siprotec Compact Motor Protection Numerical Relay is a cutting-edge solution that provides accurate and reliable motor protection, advanced communication and integration capabilities, and a user-friendly interface for easy configuration.

With its comprehensive features and benefits, the Siemens 7SK80 Siprotec Compact Motor Protection Numerical Relay can help power system operators achieve enhanced system availability and efficiency, reduce downtime, and lower maintenance costs. This blog post will delve deeper into the key features and benefits of the 7SK80 Siprotec Compact Motor Protection Numerical Relay, its various applications and use cases, as well as a case study or success story of a company that has implemented the solution. By the end of this blog post, readers will have a better understanding of how the Siemens 7SK80 Siprotec Compact Motor Protection Numerical Relay can help their power system perform better.

Benefits Of Siemens 7SK80 Motor Protection Relay

• Pluggable current and voltage terminals
• Binary input thresholds settable using DIGSI (3 stages)
• Secondary current transformer values (1 A / 5 A) settable using DIGSI
• 9 programmable function keys
• Buffer battery exchangeable from the front
• USB front port
• 2 additional communication ports
• Integrated switch for low-cost and redundant optical Ethernet rings
• Ethernet redundancy protocols RSTP, PRP and HSR for highest availability
• Relay-to-relay communication through Ethernet with IEC 61850 GOOSE
• Millisecond-accurate time synchronization through Ethernet with SNTP (over Port A or Port B)
• Number of binary binputs and inary outputs by connection from up to two SICAM I / O-Units extendable.

Applications Of Siemens 7SK80 Numerical Relay

Motor protection

Designed for protecting induction-type asynchronous motors, the SIPROTEC 7SK80 device offers specialized motor protection features.

Transformer protection

The SIPROTEC 7SK80 device offers all the fallback protection features needed for transformer differential protection. The inrush suppression successfully avoids unnecessary journeys that may be brought on by inrush currents.

Functions Of  Siemens 7SK80 Siprotec Compact Motor Protection Numerical Relay

• Definite and inverse time-overcurrent protection (phase/ground) (50, 50N, 51, 51N)
• Directional overcurrent protection, ground (definite/inverse)(67Ns, 50Ns)
• Displacement voltage, zero-sequence voltage (59N)
• Trip-circuit supervision (74TC)
• Undercurrent monitoring (37)
• Temperature monitoring (38)
• Thermal overload protection (49)
• Locked rotor protection (14)
• Directional intermittent ground fault protection (67Ns)
• Overcurrent protection, voltage controlled (51V)
• Undervoltage/overvoltage protection (27/59)
• Forward-power, reverse-power protection (32)
• Overfrequency/underfrequency protection(81O/U)
• Phase-balance current protection (negative-sequence protec-tion) (46)
• Unbalance-voltage protection and/or phase-sequence monitoring (47)

The SIPROTEC Compact devices are ideal for protection in distribution systems and industry, with minimal space requirements. Despite its compact and space-saving housing, it offers a comprehensive range of functions for both main and backup protection. With a single SIPROTEC Compact device, you can protect your system against every conceivable fault and even benefit from its control, automation, and monitoring capabilities within the substation.

We Reliserv Solution are the leading Siprotec Compact products supplier, and exporter in Mumbai, Maharashtra. Contact Reliserv Solution today to get the best price on Siemens 7SK80 Numerical Relay.  Reliserv Solution is the Authorized  Supplier & Channel Partner of SIEMENS Make Numerical Relays, Automation Products, Power Quality Meters & Instruments, MV Switchgear Spares, and PSS SINCAL Software. Additionally, we offer a variety of services and specialized solutions for industries and panel builders. Contact us at +917506112097 or mail us your requirements at [email protected] We deal in a wide range of products in Siemens, to learn more about our Siemens Siprotec Compact Relays click here.

To learn more about our products and services, contact us.
