SIEMENS RUGGEDCOM RS416 SERIAL DEVICE SERVERS
Siemens Ruggedcom RS416 Servers is a utility-grade serial device server with an integrated, fully managed Ethernet switch. It features a modular design that can support IEEE 1588 and IRIG-B time synchronization, up to 16 serial ports, and up to 4 Ethernet ports. As such, it can be used to interconnect and synchronize multiple types of intelligent electronic devices (IEDs).RUGGEDCOM RS416P The RUGGEDCOM RS416P is a utility-grade, serial device server with integrated, fully managed, 4-port Power-over-Ethernet (PoE) switch. With its modular design, it can support up to 16 serial ports and interconnect multiple types of intelligent electronic devices (IEDs) with varying methods of communication.
CYBER SECURITY
- Multilevel user passwords secure switch against unauthorized configuration SSH/SSL – extends capability of password protection to add 128-bit encryption of passwords and data as they cross the network
- Enable/disable ports – capability to disable ports so that traffic cannot pass
- 802.1Q VLAN – provides the ability to logically segregate traffic between predefined ports on switches
- MAC-based port security – provides the ability to secure ports on a switch so only specific devices / MAC addresses can communicate via a port
- 802.1x port-based network access control – provides the ability to lock down ports on a switch so that only authorized clients can communicate via a port
- RADIUS – authentication service using MD5 hash and providing centralized password management
- SNMPv3 – encrypted authentication access security and data encryption (CBC-
- DES with 56-bit encryption key)
- Secure Socket Layer – Web-based management using SSL with data encryption (128-bit encryption key)
- RSA – 1,024-bit key for key management and key exchange
- TACACS+ – Terminal Access Control and Accounting Services Client provides
- encrypted authentication and authorization
- Point-to-Point Protocol (PPP) – using CHAP (MD5 Hash) authentication service
- SFTP – Secure File Transfer Protocol using SSH encryption
Siemens Ruggedcom RS416 Servers RATED FOR RELIABILITY IN HARSH ENVIRONMENTS
- Immunity to EMI and heavy electrical surges:
– Meets IEEE 1613 (electric utility substations)
– Exceeds IEC 61850-3 (electric utility substations)
– Exceeds IEC 61800-3 (variable-speed drive systems)
– Exceeds IEC 61000-6-2 (generic industrial)
– Exceeds NEMA TS-2 (traffic control equipment)
- Fully independent 2kV (RMS) isolated serial ports
- Operating temperature: -40°C to +85°C (no fans)
- 18 AWG galvanized steel enclosure
Siemens Ruggedcom RS416 Servers FEATURES
- Simple plug and play operation – automatic learning, negotiation and crossover detection
- Integrated cyber security features
- RSTP (802.1w) and Enhanced Rapid Spanning Tree (eRSTP™) network fault
- recovery (<5 MS)
- Quality of service (802.1p) for real-time traffic
- VLAN (802.1Q) with double tagging and GVRP support
- Port rate limiting and broadcast storm limiting
- Port configuration, status, statistics, mirroring, security
MANAGEMENT TOOLS
- Web-based, Telnet, CLI management interfaces
- SNMP v1/v2/v3 (56-bit encryption)
- Remote monitoring (RMON)
- Rich set of diagnostics with logging and alarms
UNIVERSAL POWER SUPPLY OPTIONS
- Fully integrated power supplies
- PoE power supply: 48 VDC
- Unit power supply: 24 VDC (10–36 VDC), 48 VDC (36–59 VDC) or 88–300
- VDC/85–264 VAC
- Screw or pluggable terminal blocks
- Terminal blocks for reliable, maintenance-free connection
- CSA/UL 60950 safety approved to +85°C
