Siemens Ruggedcom RSG907R Compact Ethernet Switch

The RUGGEDCOM Ruggedcom RSG907R Ethernet Switch is a compact Gigabit IEEE 1588 compatible Ethernet switch supporting High Availability Seamless Redundancy (HSR) and Parallel Redundancy Protocol according to IEC 62439-3.

The RUGGEDCOM-Selector lets you configure RUGGEDCOM products quickly, easily, and efficiently, by using targeted navigation through selection menus or by entering item numbers. Selected products can then be ordered directly by transferring the parts list into the Industry Mall.

Ethernet ports

• 3 x RNA (Redundant Network Access) and coupler Ethernet ports according to IEC 62439-3 (1000BASE-X)
• 6 x SAN (Singly Attached Node) copper ports (10/100/1000BASE-TX)
• Multiple fiber connector types (SFP, LC)

Ruggedcom RSG907R Ethernet Switch Cyber security

• Passwords  support for multiple access levels with separate credentials for each level
• SSH / SSL  extends capability of password protection to add encryption of passwords and data as they cross the network
• Enable / disable ports capability to disable ports so unauthorized devices can’t connect to unused ports
• SNMPv3 encrypted authentication and access security
• HTTPS  for secure access to the web interface
• 1x  to ensure only permitted devices can connect to the device
• MAC address authentication control access to devices that do not support RADIUS

Universal power supply options

• Fully integrated redundant power supply
• Universal high-voltage input: 120 V AC/DC and 230 V AC/DC
• Dual low-voltage DC inputs: 24/48 VDC (12 ~ 60 VDC)

• Terminal blocks for reliable, maintenance-free connections
• CSA/UL 60950 safety approved to +85° C

Rugged Rated for Reliability in Harsh Environments

• Immunity to EMI and heavy electrical surges
• Zero-Packet-Loss technology
• Meets IEEE 1613 Class 2 (electric utility substations)
• Exceeds IEC 61850-3 (electric utility substations)
• Exceeds IEC 61800-3 (variable-speed drive systems)
• Exceeds IEC 61000-6-2 (generic industrial)
• Exceeds NEMA TS-2 (traffic control equipment)
• 40°C to +85°C operating temperature (fanless)
• Conformal coated printed circuit boards (optional)
• Extruded aluminum enclosure

RUGGEDCOM Operating System (ROS) Features

• Simple plug-and-play operation automatic learning, negotiation, and crossover detection
• RSTP (802.1w) and Enhanced Rapid Spanning Tree (ERSTP) network fault recovery (<5 ms)
• Quality of service (802.1p) for real-time traffic
• VLAN (802.1Q) with double tagging and GVRP support
• Port configuration, status, statistics, mirroring, security
• Loss-of-link management on fiber ports
• SNTP time synchronization (client and server)

Designed for tight spaces

Our Layer 2 Ethernet switches are specifically designed to operate reliably in industrially harsh environments.

Designed for and put to the test under the harshest environments, RUGGEDCOM products meet and exceed recognized industry standards for performance in mission-critical applications.

RUGGEDCOM Layer 2 Ethernet switches are specifically designed to operate reliably in harsh industrial environments and are available in compact and rack-mounted form factor.

RUGGEDCOM products perform at their best when the environment is at its worst, offering fast and reliable communications for electric power, transportation, oil & gas and other industries. To Explore the Ruggedcom Portfolio with us Click Here!
