Siemens Ruggedcom RST2228 Powerful High-Port Density Ethernet Switches

The RUGGEDCOM RST2228 is a field modular 19“ Layer 2 rack switch with 10 Gbit/s uplinks, support for IEEE 1588 and optional Power-over-Ethernet an ideal solution for high port density applications in the electric power, intelligent traffic systems, rail, oil&gas and other industrial communications markets.

The front loading, field replaceable module design enhances the maintainability and upgradability of the switch as it allows modules to be changed without removing the chassis from the rack. This unique design also provides future proofing of the product as it can be deployed with Gigabit uplink SFPs and 100 Mbps LAN ports initially and then upgraded to 10 gigabit uplinks and Gigabit LAN ports as data communication needs increase.

Ethernet Ports

• 4 x 1000BASE-X/10GBASE-X ports
• Up to 24 x 10/100/1000BASE-X ports
• 6 x 4-port modules for added flexibility
• Industry standard connectors: RJ45, FastConnect & SFP
• Copper, multi-mode and single-mode optical transceivers

Cybersecurity Features

• Passwords – support for multiple access levels with separate credentials for each level
• SSH / SSL – extends capability of password protection to add encryption of passwords and data as they cross the network
• Enable / disable ports – capability to disable ports so unauthorized devices can’t connect to unused ports
• SNMPv3 – encrypted authentication and access security
• HTTPS – for secure access to the web interface
• 802.1x – to ensure only permitted devices can connect to the device
• MAC address authentication – control access to devices that do not support RADIUS

Universal power supply options

• Fully integrated, optional dual redundant power supplies
• Universal high-voltage range: 88 – 300 VDC or 85 – 264 VAC
• Screw or pluggable terminal blocks for reliable, maintenance-free connections
• CSA/UL 60950 safety approved to +85° C

Precision timing

• IEEE 1588 v2 with hardware time stamping
• Transparent clock

Rugged Rated for Reliability in Harsh Environments

• Immunity to EMI and heavy electrical surges

– Zero-Packet-Loss™ technology
– IEEE 1613 Class 2
(electric utility substations)
– IEC 61850-3 (electric utility substations)
– IEC 61800-3
(variable-speed drive systems) – IEC 61000-6-2 (generic industrial)
– NEMA TS-2 (traffic control equipment)

• –40° C to +85° C operating temperature (fanless)
• Conformal coated printed circuit boards (optional)
• Aluminum and 20 Gauge Galvanized Steel construction

RUGGEDCOM Operating System (ROS®) Features

• Simple plug-and-play operation – automatic learning, negotiation, and crossover detection
• RSTP (802.1w) and Enhanced Rapid Spanning Tree (eRSTP™) network fault recovery
• Quality of service (802.1p) for real-time traffic
• VLAN (802.1Q) with double tagging and GVRP support
• Port configuration, status, statistics, mirroring, security
• Loss-of-link management on fiber ports
• SNTP time synchronization (client and server)

Ruggedcom RST2228 Ethernet Switch is designed for tight spaces

Our Layer 2 Ethernet switches are specifically designed to operate reliably in industrially harsh environments.

Designed for and put to the test under the harshest environments, RUGGEDCOM products meet and exceed recognized industry standards for performance in mission-critical applications.

RUGGEDCOM Layer 2 Ethernet switches are specifically designed to operate reliably in harsh industrial environments and are available in compact and rack-mounted form factor.

RUGGEDCOM products perform at their best when the environment is at its worst, offering fast and reliable communications for electric power, transportation, oil & gas and other industries. To Explore the Ruggedcom Portfolio with us Click Here!
