Siemens Ruggedcom RSG2488 Rack Mount Ethernet Switches

RUGGEDCOM RSG2488 Ethernet Switches are field upgradable and rugged rated for reliability in harsh environments.

Designed with flexibility and simplicity in mind, the RUGGEDCOM RSG2488 Ethernet Switches deliver optimized network availability and cost savings over the entire lifecycle.

The RUGGEDCOM RSG2488 is a utility-grade, non-blocking Layer 2 switch with 28 Gigabit ports and hot-swappable dual-redundant power supplies.

Featuring an innovative design to reduce rack space requirements, cut sparing costs, and minimize time to repair, the RUGGEDCOM RSG2488 eliminates routine maintenance and the need for separate timing cabling.

Its modular flexibility provides up to 28 non-blocking ports that can be configured as 10/100/1000TX copper, 100FX or 1000SX fiber. A 1U form factor and vertical loading design provides users with the flexibility and simplicity needed to efficiently implement, maintain and evolve a broadband local area network.

Running on the Rugged Operating System (ROS^®), it also offers precision timing, timing conversion, universal power supply options as well as cybersecurity and management tools.

The RUGGEDCOM RSG2488 is the first utility-grade, field upgradable, non blocking 28 Gigabit port layer 2 switch with hot-swappable dual redundant power supplies. The RSG2488 is designed to reduce rack space needs, cut sparing costs and minimize time-to-repair while eliminating routine maintenance and separate timing cabling, delivering increased network availability and lowest total cost of ownership.The RSG2488s modular flexibility provides up to 28 non-blocking ports that can be configured as 10/100/1000TX copper, 100FX or 1000SX fiber. With its 1U form factor and vertical loading design, the RSG2488 provides users with the flexibility and field maintenance simplicity needed to efficiently implement, maintain and evolve a broadband local area network.The RUGGEDCOM-Selector lets you configure RUGGEDCOM products quickly, easily, and efficiently, by using targeted navigation through selection menus or by entering item numbers. Selected products can then be ordered directly by transferring the parts list into the Industry Mall.

RUGGEDCOM RSG2488 Ethernet Switches PRECISION TIMING

RSG2488 can operate as an IEEE 1588 transparent clock, ordinary clock, master clock and supports both 1-step and 2-step operations. The available PTP module also allows the RSG2488 to get timing information from GPS and serve as a grandmaster clock for downstream time recipients.

TIMING CONVERSION

The RSG2488 supports IEEE 1588 (PTP), SNTP, IRIG-B and GPS. It can convert time between all of these formats.

ETHERNET PORTS

• Up to 28 Gigabit Ethernet ports – copper and/or fiber in 19″ 1U rack-mount
• 100FX or 1000SX fiber fast Ethernet ports
• 2/4 port field-replaceable Ethernet media modules for tremendous flexibility
• Supports many types of fiber (multimode, single mode, bidirectional single strand)
• Non-blocking, store and forward switching
• Hot-swappable, dual-redundant, load-sharing power supplies
• Long-haul optics allow Gigabit distances up to 70 km
• Multiple connector types (LC, SC, SFP, GBIC)

Designed for tight spaces

Our Layer 2 Ethernet switches are specifically designed to operate reliably in industrially harsh environments.

Designed for and put to the test under the harshest environments, RUGGEDCOM products meet and exceed recognized industry standards for performance in mission-critical applications.

RUGGEDCOM Layer 2 Ethernet switches are specifically designed to operate reliably in harsh industrial environments and are available in compact and rack-mounted form factor.

RUGGEDCOM products perform at their best when the environment is at its worst, offering fast and reliable communications for electric power, transportation, oil & gas and other industries. To Explore the Ruggedcom Portfolio with us Click Here!
