The RUGGEDCOM RX1500 Ethernet Switch series are cost-efficient utility grade Layer 2 and Layer 3 switches and routers. The RX1500s modular & field replaceable platform enables customers to select amongst WAN, serial & Ethernet making it suitable for the industrial plant floor, electric power utilities, rail & traffic control systems. The RUGGEDCOM-Selector allows you to configure RUGGEDCOM products easily, quickly and efficiently, by utilising targeted navigation via selection menus and also by entering item numbers

RUGGEDCOM RX1500 Ethernet Switch CYBER SECURITY FEATURES

• Integrated Router/Firewall/VPN
• Stateful Firewall with NAT
• Full IPSec Virtual Private Networking
• VPN with 3DES, AES128, AES256 support
• RUGGEDCOM CROSSBOW for NERC CIP Cyber Security Compliance
• RADIUS centralized password management
• Multi-level passwords
• SSH/SSL encryption
• Enable/disable ports, MAC-based port security
• VLAN (802.1Q) to segregate & secure network traffic
• SNMPv3 encrypted authentication & access security
• Optional Check Point Firewall & IPS (See RUGGEDCOM APE Module)

RUGGEDCOM RX1500 Ethernet PROTOCOLS

• WAN
• Frame Relay RFC 1490 or RFC 1294
• PPP RFC 1661, 1332, 1321, 1334, PAP and CHAP Authentication
• Multilink PPP RFC 1990
• GOOSE messaging Support
• IP
• Routing: OSPF, BGP, RIPv1 & 2
• VRRP
• Traffic control, NTP Server,
• IP Multicast Routing
• DCHP Agent (Option 82 Capable)
• MPLS

RUGGEDCOM RX1500 WAN PORT OPTIONS

• T1/E1 (channelized)
• E1 75 Ohms via BNC
• Cellular
• DDS

RUGGEDCOM RX1500 Ethernet FRAME RELAY SUPPORT

• ISO & ITU-compliant, network certified
• ANSI T1.617 Annex D, Q.933/LMI Local Signaling

MANAGEMENT TOOLS

• Web-based, SSH, CLI management interfaces
• SNMP v1/v2/v3
• Remote Syslog
• Rich set of diagnostics with logging and alarms
• Loopback diagnostic tests
• Raw and interpreted real timeline traces

To get the best deal on SIEMENS RUGGEDCOM RX1500 MULTI-SERVICE PLATFORM contact us as Reliserv Solution is the Best Siemens RUGGEDCOM Suppliers In India.  Reliserv Solution is the authorized Supplier & Channel Partner of SIEMENS Make Numerical Relays, Automation Products, Power Quality Meters & Instruments, MV Switchgear Spares and PSS SINCAL Software. We Reliserv Solution are the leading Siemens products supplier and exporter in Mumbai, Maharashtra. We also provide a wide range of services & customized solutions for Industries & Panel Builders. Contact us at +917506112097 or mail us your requirements at [email protected] We deal in a wide range of products in Siemens Ruggedcom to learn more about our Layer 3 Switches And Routers collection click here.
