What Are The Functions Of Siemens Siprotec 7RW80 Voltage & Frequency Protection Relay

The SIPROTEC Compact 7RW80 Voltage & Frequency Protection devices are numerical multifunction relays developed for connection to voltage transformers. These devices can be used in any distribution system, transformers as well as electrical machines. If the SIPROTEC Compact 7RW80 devices detect any deviation from the frequency or over-excitation values and permitted voltage they will respond automatically according to their values set. These devices can also be applied for the purposes of system decoupling as well as for load shedding if there is any risk of a system collapse as a consequence of inadmissibly large frequency drops. An integrated load restoration function permits the re-establishment of the power system after the recovery of system frequency.

Why Siemens Siprotec 7RW80

The 7RW80 Voltage & Frequency Protection features flexible protection functions. Users can create 20 additional protection functions. For example, a rate-of-frequency change and also a rate of- voltage change function can be created. These relays provide control on circuit-breakers and additional primary switching devices like grounding switches, transfer switches as well as isolating switches. Automation or PLC logic functionality is also provided with the relay. The integrated programmable logic (CFC) allows its user to add their own functions, for example for the automation of switchgear (including interlocking, transfer as well as load-shedding schemes). The users can also generate user-defined messages.

The communication modules are independent of the protection and you can easily exchange or upgrade to future communication protocols. Highlights-Conformal coating available (NEW) Pluggable current & voltage terminals. Binary input thresholds are settable with DIGSI (3 stages). 9 programmable function keys, 6 line displays buffer battery exchangeable from the front USB front port. 2 additional communication ports Integrated switch for low-cost & redundant optical Ethernet rings, Ethernet redundancy protocols RSTP, PRP & HSR for highest availability. Relay-to-relay communication via Ethernet with IEC 61850 GOOSE Millisecond accurate time synchronization via Ethernet with SNTP.

Protection Functions Of Siemens Siprotec 7RW80 Voltage & Frequency Protection Relay

• Under-/overvoltage protection (27/59)
• Frequency protection (81U/O)
• Load restoration Overexcitation protection (24)
• Jump of voltage vector Synch-check (25)
• Lockout (86)

Control Functions/Programmable Logic Of Siemens Siprotec 7RW80 Voltage & Frequency Protection Relay

• Commands for the control of CB, disconnect switches (isolators or isolating switches)
• Control through keyboard, binary inputs, DIGSI 4 and SCADA system
• User-defined PLC logic with CFC (e.g. interlocking)

Monitoring Functions

• Operational measured values V, f
• Minimum and maximum values
• Trip circuit supervision
• Fuse failure monitor
• 8 oscillographic fault records

Communication Interfaces

• System/service interface
  • -IEC 61850
  • -IEC 60870-5-103
  • -PROFIBUS-DP
  • -DNP 3.0
  • -Ethernet redundancy protocols RSTP, PRP and HSR
• Ethernet interface for DIGSI 4
• USB front interface for DIGSI 4

Hardware

• 3 voltage transformers
• 3/7 binary inputs (thresholds configurable using software)
• 5/8 binary outputs (2 changeovers)
• 1 life contact
• Pluggable terminals-blocks
• Conformal coating available (NEW)

Perfectly suited for protection in distribution systems and industries with minimal space requirements. SIPROTEC Compact devices from Siemens provide a comprehensive range of functions in surprisingly compact & space-saving housing. Whether as main or as backup protection, a single SIPROTEC Compact device can provide protection functionality for every conceivable fault in the system. And it can also do more like supporting the control, automation, & monitoring functions in the substation.

Siemens is one of the most trusted and oldest leading MNCs in India thanks to its quality products for diverse types of power systems. To get the best deal on Siemens 7RW80 Siprotec Voltage and Frequency Protection Relay contact us as Reliserv Solution is the authorized Supplier and also Channel Partner of SIEMENS Make Numerical Relays, Automation Products, Power Quality Meters & Instruments, MV Switchgear Spares, PSS SINCAL Software. We Reliserv Solution are the leading Siemens 7RW80 Siprotec Relay products supplier and exporter in Mumbai, Maharashtra. We also provide a wide range of services & customized solutions for Industries & Panel Builders. Contact us at +917506112097 or mail us your requirements at [email protected]. We deal in a wide range of products in Siemens to learn more about our Siemens Numerical Relay collection click here.
