Siemens SICAM Q100 Power Quality Instrument/Recorder popularly known as Q100 power quality recorder multifunctional measuring devices are used for visualization, acquisition, evaluation & transmission of electrically measured variables such as alternating voltage, alternating current, power, frequency, harmonics etc.  The acquisition, processing & accuracy of measured variables and events are performed in accordance with the IEC 61000-4-30 Class A power quality measurement standard.

The measured variables can be output to a PC and also the system control with the help of communication interfaces and it can also be shown on display. In addition to its monitoring function, the Siemens Q100 Power Quality Instruments are all-in-one devices that offer combined recording and evaluating functions: measured values are recorded in parameterizable time intervals with different recorders (power quality and fault recorders). Longtime data and events are evaluated directly in SICAM Q100 Power Quality Recorder and displayed as a report in accordance with the power quality standards (e.g., EN 50160).

Siemens Q100 Power Meter Applications

Power Quality – Supply Quality

Quality is generally regarded as an essential aspect of any power supply. Insufficient power supply quality generally has a negative impact on operational processes as well as the operational safety of consumers associated with the network. Siemens SICAM Q100 Power Quality Instrument/recorder can entail major consequences, which can ultimately result in increased costs for the user & supply utility.

The EN 50160 power quality standard helps in describing the main voltage characteristics at the supply terminal of customers in public low, medium & high-voltage systems. Documentation of parameters relevant to the supply quality and Comprehensive acquisitions are necessary steps for identifying possible weak points and initiating appropriate measures to eliminate them.

Siemens Q100 Power Meter Application

The SICAM Q100 devices are used in single-phase, three-wire and four-wire systems (with neutral conductor). These devices are applied wherever comprehensive measurement of supply quality is essential – at power utilities and industries as well as trade sectors.

SICAM Q100 Device Technical Specification

Input Measuring Circuits

• 4x alternating voltage, 4x alternating current

Binary Input/Outputs

• 2 individually programmable binary inputs & outputs
• Binary expansion (with additional 12 inputs & 12 outputs) by implying SICAM I/O Unit devices

Q100 Power Quality Recorder Measured Variables

• Measured value acquisition in accordance with the IEC 61000-4-30 Class A power quality measurement standard
• Mean value, event & fault recorder functionality
• Load Profile & TOU (Time of use, 2 x Tariffs)
• Power frequency, power factor & active power factor, active, reactive & apparent power and phase angle
• Alternating voltage & current harmonic up to the 63rd order

Siemens Sicam Q100 Power Quality Instrument Communication Interfaces & Protocols

• Ethernet: MODBUS TCP & IEC 61850 Edition 2
• MODBUS Master & Gateway functions for RS485 devices (as Switcher 3WL, SICAM P50 &  PAC3x00)

Siemens SICAM Q100 Power Quality Instrument Operation & Display

• Full graphic display, operation through 4 function keys
• Integrated web server to easily interact with PC through TML pages

Siemens SICAM Q100 Power Quality Instrument Time Synchronization

• Through Ethernet: NTP client (Network Time Protocol)

Auxiliary Voltage

• DC 24 – 250 V
• AC 110 – 230 V, 50/60 Hz

Housing Specification

• Compact dimensions: 96 x 96 x 100 mm (W / H / D)

Special Features Of Siemens SICAM Q100 Power Quality Instrument

• PQ reporting according to EN 50160 & CBEMA direct over HTML web server
• Evaluation of events directly in HTML through COMTRADE Viewer/SIGRA Plugin
• Flexible data export in the PQDIF, COMTRADE & CSV format
• Memory capacity of 2 GB for storage of the recorder data for years of power-quality data
• MODBUS Master & Gateway function

Many electronic devices & automation systems in industrial production plants are delicate towards voltage variations & dips in the power supply which are usually caused by the unexpected connection of energy sources like renewable energy & large energy consumers. The production system itself can also cause faults and feed them back into the distribution system. The plants can be shut down and you will suffer major production loss. Power quality needs to be continuously measured & analysed to detect any type of unexpected risks early on.

Conclusion

In conclusion, the Siemens SICAM Q100 Power Quality Instrument/Recorder is a powerful tool that can help industries improve their power quality, reduce energy costs, and optimize their energy use. With its advanced features and capabilities, the device offers a comprehensive solution for monitoring, analyzing, and addressing power quality issues. Industries that invest in the Siemens SICAM Q100 can benefit from improved operational efficiency, reduced downtime, and increased profitability.
